Riverbed SteelFusion Edge 2200 - Replacing Steelfusion Edge Components; Field-Replaceable Units

SteelFusion Edge Hardware and Maintenance Guide 43
4
Replacing SteelFusion Edge Components
This chapter describes how to replace components in SteelFusion Edge appliances. It includes the
following sections:
 “Field-replaceable units” on page 43
 “Required tools” on page 44
 “Opening the bezel” on page 44
 “Removing the chassis cover” on page 46
 “Replacing disk drives” on page 47
 “Replacing power supply units” on page 51
 “Adding and replacing memory modules” on page 52
 “Replacing fans” on page 67
Field-replaceable units
The SteelFusion Edge appliances contain several field-replaceable units (FRUs) that you or a certified
service technician can troubleshoot, remove from the system, and replace without having to send the
system to a repair facility.
Caution: Perform troubleshooting or repairs only as directed in the product documentation or by the online or
telephone service and support team. All other servicing should be performed by a certified technician. Your
warranty does not cover damage due to servicing that is not authorized by Riverbed.
Note: For a list of supported NICs, see Chapter 3, “Installing Network Interface Cards in SteelFusion Edge
Appliances.”
The following table lists the FRUs available for the SteelFusion Edge appliances.
FRU Description SFED Appliance Instructions
MEM-1-002 8 GB DRAM DIMM 2100, 2200, 3100,
3200, 5100
“Adding and replacing memory
modules”
MEM-1-003 16 GB 1600, x4/DR, 16 GB RAM 2100, 2200, 3100,
3200, 5100
“Adding and replacing memory
modules”
