78 SteelFusion Edge Hardware and Maintenance Guide
SteelFusion Edge Technical Specifications 1U SteelFusion Edge specifications
Technical specifications
The following table lists the technical specifications for the appliances.
Note: This table indicates the SSD disk capacity available to the appliance. Replacement disks might be capable
of a higher capacity (such as 200 GB instead of 120 GB), but the appliance still limits them to the capacity expected
by the system and defined in this table.
Environmental specifications
This table summarizes the environmental requirements for the 1U SteelFusion Edge appliances.
SteelFusion Edge 2100 SteelFusion Edge 2200
Form factor
1U 1U
Dimensions (HxWxD)
1.72 x 17.2 x 25.4 in
(43.6 x 436 x 644.4 mm)
1.72 x 17.2 x 25.4 in
(43.6 x 436 x 644.4 mm)
Weight (without packaging)
36 lb (16.33 kg) 36 lb (16.33 kg)
PCIe slots
2 2
Bypass ports/max # ports
2/2 2/2
HDD
2 x 1TB 2 x 2 TB
SSD
2 x 100 or 2 x 120 GB 2 x 100 or 2 x 120 GB
Data store
170 GB 170 GB
Blockstore
750 GB 1500 GB
CPU
E5-2609v2 2.5 GHz
4 Cores
E5-2609v2 2.5 GHz
4 cores
SteelFusion Edge 2100 and 2200
Operating
Acoustic
46.4 dBA Sound pressure (Typical)
Temperature (Operating)
10º–40ºC
50°–104ºF
Temperature (Storage)
-40º–65ºC
-40º–149ºF
Relative humidity need
20%–80% noncondensing
Storage humidity need
5%–95% noncondensing
Operating altitude
Up to 10,000 ft
(Up to 3048 m)
