SteelFusion Edge Hardware and Maintenance Guide 23
Mounting the SteelFusion Edge appliances using the extendable rail Rack Mounting the SteelFusion Edge Appliances
Mounting the SteelFusion Edge appliances using the
extendable rail
This section describes how to mount an appliance using the extendable rail (RMK-2-EXPRAIL) and
contains the following procedures:
 “Setting up the rails” on page 23
 “Mounting the appliance” on page 23
 “Operating the rails” on page 25
 “Center mounting 1U appliances in a two-post rack” on page 25
Setting up the rails
To set up the rails, attach the inner rails to the appliance. (See Figure 2-1.)
Figure 2-1. Attaching the inner rails
Mounting the appliance
After you have adjusted the length of the outer rails to fit your rack posts, you are ready to install the
outer rail assemblies to the rack.
Note: All 2U appliances must be mounted to a four-post rack.
Caution: A minimum of two people is required to move a 2U appliance. Lift the appliance using both hands and with
your knees bent.
