80 SteelFusion Edge Hardware and Maintenance Guide
SteelFusion Edge Technical Specifications Power specifications
Power specifications
This table summarizes the power specifications for the SteelFusion Edge appliances.
SFED 2100
SFED 2200
SFED 3100 SFED 3200 SFED 5100
Chassis
1U 2U 2U 2U
PSU type
2 x 770 W 2 x 1000 W 2 x 1000 W 2 x 1000 W
Input power
100–127 VAC 10 A 50–60 Hz
200–240 VAC 5 A 50–60 Hz
100–127 VAC 12.47 A 50–60 Hz
200–240 VAC 7.08 A 50–60 Hz
AC input
120 V 230 V 120 V 230 V 120 V 230 V 120 V 230 V
Max. amps
3.0 1.4 5.0 2.1 6.2 2.5 6.5 2.6
Max. watts
364 369 597 590 750 745 773 763
Typical watts
291 295 478 472 600 596 619 611
Max. VA
367 392 615 627 766 768 789 787
Power factor
99 94 97 94 98 97 98 97
BTU
992 1006 1629 1609 2047 2032 2109 2083
