FAULT INFORMATION
101
Poor drive force on rotary
arm
Excessive friction on rotary
arm drive parts.
Contact technical support.
Brake on rotation motor not
released
Adjust the brake gap on the arm rotation motor.
Contact technical support.
Rubber roller jammed on
carriage
- Reduce the tension through the braking knob on-
board the carriage.
- Check that the roller is idling when released from
the brake.
Inspect and remove, if necessary, any fragment of
film in the lower side of the roller.
Brake release control
activated
Rotate the brake release button to standard position.
Unsynchronised stop
Chain elongation
Adjust chain tension and replace if necessary.
Pay attention not to tension it excessively.
Minimum perimeter clearance of 10 cm.
See "Wrapping machine arm drive chain tension
adjustment".
Excessive movement of
the rotary arm in rest
position
Chain elongation
Adjust chain tension and replace if necessary. Pay
attention not to tension it excessively.
Minimum perimeter clearance of 10 cm.
See “Wrapping machine arm drive chain tension
adjustment”.
Noise at rotation motor
Chain elongation
Adjust chain tension and replace if necessary.
Reduction unit
Check operation.
Wrong gap
Adjust the brake gap on the arm rotation motor.
Contact technical support.
Arm rotation alarm (E61)
Arm jamming
Check that the drive parts are in perfect conditions.
The inductive sensor does not
read the cam
Adjust the distance of the inductive sensor from the
cam.
Alarms (E02)
Contact of the arm with an
obstacle
Remove the obstacle. If necessary, move the arm
using the brake release button.
Deformation of the sensor
inside the sensible edge
Manually handle the sensible edge in the contact
area. If the control unit does not reset it is necessary
to replace the sensible edge.
Breakage of the sensible edge
Replace component.
Breakage of the control unit
Replace component.
