Robopac MASTERWRAP PLUS XL FR - KEY TECHNICAL SPECIFICATIONS

ENG
TECHNICAL INFORMATION
29
3.6. TECHNICAL SPECIFICATIONS
Description
Unit of
measurement
Value
Ecowrap XL
Plus FRD
h=2000
Masterwrap
XL Plus FR
h=2000
Ecowrap XL
Plus FRD
h=2400
Masterwrap
XL Plus FR
h=2400
Supply voltage
220-240 1 Ph
220-240 3 Ph
380-415 3 Ph+ N
Electrical current frequency
Hz
50/60
Installed power
kW
0.7
Wrapping speed
turns/min
7 ÷ 11
Carriage upstroke /
downstroke speed
m/min
2.6 ÷ 6.0
Overall weight
kg
200
200
215
215
Ambient operating
temperature
°C
0 ÷ 40
Installation area floor characteristics
Concrete foundation with
resistance to compression in
compliance with UNI 6132
C25-30
Foundation minimum thickness
mm
150
Diameter of the reinforcement
rods of the framework in
metallic cage
mm
8
