Robopac MASTERWRAP PLUS XL FR - Work Area Delimitation Barrier Installation (Optional)

ENG
INFORMATION ON HANDLING AND INSTALLATION
43
4.4.3. WORK AREA DELIMITATION BARRIER INSTALLATION (OPTIONAL)
1. Identify the installation position of the barrier (A).
2. Drill the holes (ø10 x 70mm) on the floor in correspondence of the barrier fastening holes.
Important
Thoroughly clean the holes to eliminate any residual material.
3. Fix the stop device to the ground by means of plugs (B).
