6.2. DESCRIPTION OF CONTROLS (ECOWRAP PLUS)
A) Emergency stop button:
it is used in case of imminent risk to stop, with a voluntary action, the machine parts which may pose a risk.
For further details, see the paragraph “description of safety devices”.
B) “Cycle start” button:
it is used to start the wrapping automatic cycle.
C) “Cycle stop” button:
it is used to stop the wrapping automatic cycle.
D) Multi-function selector:
it allows activating and setting machine functions.
Turn the selector (clockwise or counter-clockwise) until the LED for the desired function turns on.
E) Digital display:
it shows the working parameters and alarm codes.
F) Machine functions:
- F1-F8: these are the various functions available on the machine (see the “Machine functions” section).
G) “Reset” button:
it is used to reset the machine before restarting it after an emergency stop or after a shut-down due to the
disconnection of the power supply.
H) Key-operated switch:
- Carriage emergency override
Rotate the key clockwise in hold to run position: the user interface screen will display the page “emergency
override” and this allows the carriage alone to be lifted by simultaneously pressing the “multi-function selector”
(D).
- Rotary arm brake release
Rotate the key counter-clockwise (stable position): it is used to release the rotary arm and move it manually
(see “Safety device description”).
J) USB port:
used to update the machine software.
If a USB flash drive containing updated software is inserted into the port, the software will be installed on the
machine when it is turned on.
K) Main disconnector:
it enables and disables the power supply.
Pos. “O”: power supply off.
Pos. “I”: power supply on.
