Robopac MASTERWRAP PLUS XL FR - Page 57

ENG
INFORMATION ABOUT THE USE
57
3
P
Carriage “Home” height adjustment
R
Carriage “Home” height adjustment, by rotating the multi-function selector, the
height can be adjusted at 5-centimetre intervals, up to a maximum height of 1
metre
4
P
Carriage upstroke / downstroke speed adjustment
R
Carriage upstroke / downstroke speed adjustment via the rotation of the multi-
function selector.
5
P
Adjustment of the number of cycles at the top of the pallet
R
Adjustment of the number of cycles at the top of the pallet via the rotation of the
multi-function selector.
6
P
Manual controls
P
Carriage downstroke in manual mode by keeping the multi-function selector
turned to the left
P
Carriage upstroke in manual mode by keeping the multi-function selector turned
to the right
7
P
Adjustment of the number of cycles at the base of the pallet
R
Adjustment of the number of cycles at the base of the pallet via the rotation of
the multi-function selector.
8
R
Machine rotation speed adjustment
R
Machine rotation speed adjustment (max speed 11 RPM)
