Rockwell Automation Publication 5069-UM003B-EN-P - January 2020 103
Compact 5000 I/O Serial Module Configuration Chapter 4
Figure 56 - Channel Parameters
For module function definitions, see Common Module Functions on page 30
Figure 57 - Transmission Settings
For DH-485 function definitions, see DH-485 Functions on page 69
