Rockwell Automation Allen-Bradley Compact 5000 Series User Manual

102 Rockwell Automation Publication 5069-UM003B-EN-P - January 2020
Chapter 4 Compact 5000 I/O Serial Module Configuration
DH-485
Figure 54 - Connection
Figure 55 - Module Info
Figure 56 and Figure 57 show the communication port that defines the baud rate
and transmission settings.
