Rockwell Automation Publication 2711R-UM001H-EN-E - April 2021 63
Chapter 3 DesignStation in Connected Components Workbench Software
Add Fonts to the Terminal To add fonts to a PanelView 800 terminal, you must first import them into
Connected Components Workbench software. The font types supported are
“.ttf”, “.ttc”, and “.ac3”.
Follow these steps to download a font to the terminal.
1. In Connected Components Workbench software, click Device ->
Download -> Download Font.
2. If the font you want to download to the terminal is not shown in the
Download Font window, click Import.
3. Browse your computer for the font, then select it and click Open.
The font is now imported into Connected Components Workbench
software.
IMPORTANT
The Korean language font “Gulim” is treated as a system font. After
downloading it to the terminal After downloading it to the terminal and
restarting the terminal, you can switch the terminal language to Korean
by selecting it from the main configuration screen. See Select a
Terminal Language on page 19. The “Gulim” font will not appear in the
Font screen and cannot be deleted unless you restore or return the
terminal to out-of-box condition.
If your application uses a font that is not in the terminal, the font will be download
to the terminal together with your application.
