42 Rockwell Automation Publication 2711R-UM001H-EN-E - April 2021
Chapter 2 Configure the Terminal
Print Type = Print Current Screen, Print Alarm History.
System Information Settings On the main configuration screen, press System Information to go to the
sy
stem information screen.
You can perform the following actions under System Information:
View System Information
Change Daylight Savings Time and Timezone
View System Information
You can view system information about your terminal including information
about the firmware, boot code, logic board, battery status (if applicable),
terminal on time, and memory used.
Follow these steps to view system information from the terminal.
1. Press System Information.
The system information screen displays firmware revision, boot code
version, logic board version, terminal on time, display on time, and
battery status
.
IMPORTANT
The portrait and color options are not supported when printing the
alarm history. The print settings switches automatically to the
landscape and monochrome options.
System Information
Main
Advanced
Firmware Version:
Boot Code Version:
Logic Board Version:
Terminal On Time:
Display On Time:
Battery Status:
Memory Usage (bytes)
Internal Used:
Internal Free:
Application Used:
Application Free:
5.011
4.011
4
102,330
102,330
Good
1,392,640
164,741,120
31,600,640
193,994,752
