Rockwell Automation Publication 2711R-UM001H-EN-E - April 2021 75
Chapter 3 DesignStation in Connected Components Workbench Software
From the Object Properties, click Format, set the attribute Time Datatype
Entry to True. When changing the time in the application, the value is
displayed in the onscreen keyboard.
View List of Objects In Connected Components Workbench software version 13 or later, you can
view a list of all the objects in your application screens in the Object Explorer
window. Use the Object Explorer to help you manage and identify the objects
in your application.
To access the Object Explorer window, select it from the View menu. You can
dock it within the workspace or as a tab.
The Object Explorer shows a list of the objects that are used under each
application screen. Selecting the object in the Object Explorer window selects
it in the application screen.
Options Description
Lock
Locks the selected object. The object cannot be selected in the application screen.
Unlock
Unlocks the selected object.
Unlock all
Unlocks all objects
Vibrate
Vibrates the selected object in the application screen.
Visibility
Click the eye icon next to the object to Show/Hide the object in the application screen. If an object is
hidden, the eye icon is grayed and struck out, it means that one or more objects in that screen are
hidden. Click the eye icon to Show/Hide all the objects in that screen.
Search Object Enter the name of the object to search for it in the list.
Filter on screen Filters the objects in the application screen that match the name entered in the Search Object field.
