Roland JUPITER-X Reference Manual

18
Performing
Adjusting the Mic Settings
Depending on the environment in which you’re performing, noise
from the surroundings might be picked up by the mic, causing the
vocoder to not work as you intend.
In this case, adjust the microphone sensitivity and the noise
suppressor (NS) settings, so that it is less likely to pickup noise.
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM,” and then press
the [ENTER] button.
You can also make this selection by using the PAGE [ ] [ ]
buttons instead of the [1] knob.
3. Use the [1] knob to select a parameter, and use the [2]
knob to edit the value.
MIC IN parameters
Parameter
[1] knob
Value
[2] knob
Explanation
Mic In Gain -24.0–+24.0 [dB] Adjusts the input level of the MIC IN jack.
Mic Power OFF, ON
If this is “ON,” plug-in power (5 V) is
supplied to the MIC IN jack.
NS Switch OFF, ON
Switches the noise suppressor on/o.
The noise suppressor is a function that
suppresses noise during periods of
silence.
NS Threshold -96–0 [dB]
Adjusts the volume at which noise
suppression starts to be applied.
NS Release 0–127
Adjusts the time from when noise
suppression starts until the volume
reaches 0.
CompSwitch OFF, ON
Species whether the mic compressor (a
compressor applied to the mic input) is
used (ON) or not used (OFF).
CompAttack 0.1, 1, 2, ...100 [ms]
Species the time from when the input
to the mic compressor exceeds the
Comp Thres level until the volume is
compressed.
CompRelease 10, 20, ...1000 [ms]
Species the time from when the input to
the mic compressor falls below the Comp
Thres level until compression is no longer
applied.
CompThreshold -60–0 [dB]
Species the level at which the mic
compressor starts applying compression.
CompRatio
1: 1, 2: 1, ...4: 1, 8: 1,
16: 1, 32: 1, INF: 1
Species the compression ratio for the
mic compressor.
CompKnee 0–30 [dB]
Smooths the transition until the mic
compressor starts to be applied.
Higher values produce a smoother
transition.
CompOutGain
-24.0, -23.5, ... 0, ...
+24.0 [dB]
Species the output volume of the mic
compressor.
Rev Send Lev 0–127
Species the amount of reverb that is
applied to the mic input.
Cho Send Lev 0–127
Species the amount of chorus that is
applied to the mic input.
Dly Send Lev 0–127
Species the amount of delay that is
applied to the mic input.
Mic Thru OFF, ON
If you want the mic to be cut when the
vocoder is o, turn this “OFF.”
4. If you want to save the setting, execute the System
Write operation.
& “Saving the System Settings (System Write)” (p. 43)
Preventing acoustic feedback
Acoustic feedback could be produced depending on the location of
microphones relative to built-in speakers (or the external speakers).
This can be remedied by:
5 Changing the orientation of the microphone(s).
5 Relocating microphone(s) at a greater distance from speakers.
5 Lowering volume levels.
Performing with a Connected Computer
or Other External Device
You can connect a computer and use a plug-in synth in combination
with this unit, or use it together with a product that is compatible with
AIRA-LINK and enjoy synchronized performances.
& “Control” (p. 39)

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
