Roland JUPITER-X Reference Manual

41
Control
Using I-ARPEGGIO Sync Mode
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM,” and then press
the [ENTER] button.
You can also make this selection by using the PAGE [ ] [ ]
button instead of the [1] knobs.
3. Use the [1] knob to select “Arp Sync,” and use the [2]
knob to specify either “BEAT” or “MEASURE.”
BEAT: The arpeggio plays in synchronization with the beat.
MEASURE: The arpeggio plays in synchronization with the
measure.
4. To save the setting, perform the system write
operation.
&“Saving the System Settings (System Write)” (p. 43)
Controlling from an External Device
You can operate the JUPITER-X via the MIDI IN connector, USB MIDI IN
port, or by using controllers such as a damper pedal etc. connected to
the rear panel.
& “List of functions that can be assigned to the controllers”
(p. 47)

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
