Roland JUPITER-X Reference Manual

40
Control
Adjusting the USB audio output
Here’s how to adjust the volume of the audio that is output from
the JUPITER-X to a computer or other USB-connected device.
1. Press the [MENU] button.
The setting screen appears.
2. Use the [1] knob to select “SYSTEM,” and then press
the [ENTER] button.
You can also make this selection by using the PAGE [ ] [ ]
buttons instead of the [1] knob.
3. Use the [1] knob to select “USB Out Lev.”
4. Use the [2] knob to adjust the volume.
5. To save the setting, perform the system write
operation.
&“Saving the System Settings (System Write)” (p. 43)
Controlling MainStage (DAW CTRL Function)
You can use the sliders, knobs, and buttons of the JUPITER-X to control
MainStage (DAW CTRL function).
In order to use this function, you’ll need to install the dedicated
“MainStage prole” in addition to the USB driver.
For details on how to install the prole and use the DAW CTRL
function, refer to “MainStage Prole Usage Guide” (PDF).
Controller Function
[SHIFT] button+
[MENU] button
Switch the JUPITER-X to DAW CTRL mode.
[EXIT] button Exit DAW CTRL mode and return to the normal state.
[1] knob
Set Select
Change the set.
PAGE [>] button
Next Set
Recall the next set.
PAGE [<] button
Previous Set
Recall the previous set.
[2] knob
Patch Select
Change the patch.
PAGE [
] button
Next Patch
Recall the next patch.
PAGE [
] button
Previous Patch
Recall the previous patch.
[AMP LEVEL] knob
Volume
Adjust the master volume.
[ENV1 Attack] slider
Smart Control
Edit the Smart Control parameters.
[ENV1 Decay] slider
[ENV1 Sustain] slider
[ENV1 Release] slider
[ENV2 Attack] slider
[ENV2 Decay] slider
[ENV2 Sustain] slider
[ENV2 Release] slider
Connecting External Devices
Controlling an External MIDI Device
MIDI messages can be sent from the MIDI OUT connector and from
USB MIDI OUT when you operate the controllers of this unit, such as
the knobs and keyboard, and the various pedals connected to the rear
panel.
Specifying the MIDI channel
1.
Press the [SCENE] button.
2. Press the PAGE [>] button twice to access the scene
part edit screen.
3. Use the [1] knob to select “Rx Ch,” and use the [2]
knob to specify the channel.
4. To save the setting, perform the scene write
operation.
&“Saving the Scene Settings (SCENE WRITE)” (p. 25)
Specifying the MIDI output
1.
Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM,” and then press
the [ENTER] button.
You can also make this selection by using the PAGE [ ] [ ]
button instead of the [1] knobs.
3. Use the [1] knob to select “MIDI Tx” for the parameter
that you want to output, and use the [2] knob to
specify “ON.”
For details, refer to “Parameter Guide” (PDF).
4. To save the setting, perform the system write
operation.
&“Saving the System Settings (System Write)” (p. 43)
Using the AIRA LINK Function
AIRA LINK lets you connect the AIRA MIXER MX-1 and the
JUPITER-X via a single USB cable. This lets you easily enjoy
synchronized performances using I-ARPEGGIO.
You can also link multiple JUPITER-X units.
NOTE
In order to use this function, the SYSTEM parameter USB Driver
must be set to “VENDOR.”
& “USB driver settings” (p. 39)
Settings on the JUPITER-X
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM,” and then press
the [ENTER] button.
You can also make this selection by using the PAGE [ ] [ ]
button instead of the [1] knobs.
3. Use the [1] knob to select “Sync Mode,” and use the [2]
knob to specify either “AUTO” or “USB.”
4. To save the setting, perform the system write
operation.
&“Saving the System Settings (System Write)” (p. 43)

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
