Editing a Tone (TONE EDIT)
Section Controller Parameter
Destination or operation when
used with the [SHIFT] button
LFO
1
Pitch Select PITCH-LFO (*1) -
2
FILTER Select FILTER-LFO (*1) -
3
AMP Select AMP-LFO (*1) -
4
LFO2 Select LFO2 -
5
TYPE L1/2 Waveform
TONE EDIT > L1/2
Waveform
6
DEPTH
If “PITCH-LFO” is selected
L1/2 Pit Depth
TONE EDIT > L1/2 Pit
Depth
If “FILTER-LFO” is selected
L1/2 Flt Depth
TONE EDIT > L1/2 Flt
Depth
If “AMP-LFO” is selected
L1/2 Amp Depth
TONE EDIT > L1/2 Amp
Depth
7
RATE L1/2 Rate TONE EDIT > L1/2 Rate
8
FADE TIME L1/2 Fade Time
TONE EDIT > L1/2 Fade
Time
OSC
9
OSC1 SEL Select PARTIAL1 PARTIAL1 Sw ON/OFF
10
OSC2 SEL Select PARTIAL2 PARTIAL2 Sw ON/OFF
11
OSC3 SEL Select PARTIAL3 PARTIAL3 Sw ON/OFF
12
OSC4 SEL Select PARTIAL4 PARTIAL4 Sw ON/OFF
13
RING
Select RING MOD
MODE
TONE COMMON EDIT >
Struct12/34
14
SYNC
Select SYNC MOD
MODE
TONE COMMON EDIT >
Struct12/34
15
XMOD
Select XMOD MOD
MODE
TONE COMMON EDIT >
Struct12/34
16
TYPE
Simultaneously
change OSC Type /
Wav Form
TONE EDIT > Wav Form
17
MOD
If “MOD” is selected
Pulse Width
TONE EDIT > Pulse Width
If “RING” is selected
Ring OSC2/4 Lv
TONE COMMON EDIT >
Ring OSC2/4 Lv
If “SYNC” is selected
Pulse Width
TONE EDIT > Pulse Width
If “XMOD” is selected
XMd12 Dpth
TONE COMMON EDIT >
XMd12 Dpth
18
Pitch Coarse Tune TONE EDIT > Coarse Tune
19
DETUNE Fine Tune TONE EDIT > Fine Tune
20
OSC1 LEVEL PARTIAL1 LEVEL
TONE EDIT PARTIAL1 >
Level
OSC
21
OSC2 LEVEL PARTIAL2 LEVEL
TONE EDIT PARTIAL2 >
Level
22
OSC3 LEVEL PARTIAL3 LEVEL
TONE EDIT PARTIAL3 >
Level
23
OSC4 LEVEL PARTIAL4 LEVEL
TONE EDIT PARTIAL4 >
Level
FILTER
24
[R]
Change VCF TYPE
TONE EDIT > VCF Type
25
[M]
Change VCF TYPE
TONE EDIT > VCF Type
26
[S]
Change VCF TYPE
TONE EDIT > VCF Type
27
KEY-FOLLOW Cuto Keyf TONE EDIT > Cuto Keyf
28
TYPE
Simultaneously
change TVF Type /
Filter Type / Flt Slope
/ VCF Type
TONE EDIT > VCF Type
29
CUTOFF Cuto TONE EDIT > Cuto
Section Controller Parameter
Destination or operation when
used with the [SHIFT] button
FILTER
30
RESONANCE Resonance TONE EDIT > Resonance
AMP
31
LEVEL
If “Part1–4” is selected
Level
TONE COMMON EDIT
> Level
If “Part5” is selected
Part Level
SCENE PART EDIT > Part
Level
ENV1/2
32
DEPTH
If “PITCH ENV” is selected
Pit Depth
TONE EDIT > Pit Depth
If “FILTER ENV” is selected
Filtr Depth
TONE EDIT > Filtr Depth
If “AMP ENV” is selected
Not operable
-
33
Pitch Select PITCH ENV -
34
FILTER Select FILTER ENV -
35
AMP
Select AMP ENV
(always)
-
36
A
If “PITCH ENV” is selected
Pit Time1
TONE EDIT > Pit Time1
If “FILTER ENV” is selected
Filtr Time1
TONE EDIT > Filtr Time1
If “AMP ENV” is selected
Amp Time1
TONE EDIT > Amp Time1
37
D
If “PITCH” is selected
Pit Time3
TONE EDIT > Pit Time3
If “FILTER ENV” is selected
Filtr Time3
TONE EDIT > Filtr Time3
If “AMP ENV” is selected
Amp Time3
TONE EDIT > Amp Time3
38
S
If “PITCH” is selected
Pit Lv3
TONE EDIT > Pit Lv3
If “FILTER ENV” is selected
Filtr Lv3
TONE EDIT > Filtr Lv3
If “AMP ENV” is selected
Amp Lv3
TONE EDIT > Amp Lv3
39
R
If “PITCH” is selected
Pit Time4
TONE EDIT > Pit Time4
If “FILTER ENV” is selected
Filtr Time4
TONE EDIT > Filtr Time4
If “AMP ENV” is selected
Amp Time4
TONE EDIT > Amp Time4
EDIT
40
MONO
MONO
TONE COMMON EDIT >
Mono Poly
For VOCODER
MONO
SCENE PART EDIT >
Mono/Poly
41
UNISON
UNISON
TONE COMMON EDIT >
Unison Sw
For VOCODER
UNISON
SCENE PART EDIT >
Unison Sw
42
VELOCITY OFF VELOCITY OFF
SCENE PART EDIT > KBD
Velo
43
PORTAMENTO PORTAMENTO
TONE COMMON EDIT >
PORTA TIME
44
SPLIT SPLIT -
45
DUAL DUAL L/R DUAL
* 1 The priority order for LFO type is PITCH > FILTER > AMP.
