Roland JUPITER-X Reference Manual

7
Panel Descriptions
13
Controller section
[VOLUME] knob
Adjusts the overall volume.
[WHEEL 1] [WHEEL 2] wheels
Control the parameters that are assigned to the wheels.
If you hold down the [SHIFT] button and operate one of these
controllers, the corresponding parameter assignment screen
appears.
[SL1] [SL2] sliders
Control the parameters that are assigned to the sliders.
If you hold down the [SHIFT] button and operate one of these
controllers, the corresponding parameter assignment screen
appears.
[TRANSPOSE] button
Switches transposition on/o. By holding down this button and
using the OCTAVE [-] [+] buttons, you can transpose the pitch of
the keyboard in semitone steps.
OCTAVE [-] [+] buttons
Shift the pitch of the keyboard in units of one octave.
[S1] [S2] [S3] buttons
Control the parameters that are assigned to the buttons.
If you hold down the [SHIFT] button and operate one of these
controllers, the corresponding parameter assignment screen
appears.
Pitch bend/modulation lever
This allows you to control pitch bend or apply vibrato.
A
PHONES jack
Connect stereo mini-type headphones here.

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
