Roland V-1HD+ - 8: AUDIO INPUT Menu Options (continued)

53
Menu List
Menu item Value (bold text: default value) Explanation
MONO
Converts the input audio from stereo to mono.
OFF Sends the stereo input audio without change.
L MONO The audio of the L channel is sent to both L and R.
R MONO The audio of the R channel is sent to both L and R.
LR MIX The audio of the L channel and R channel is mixed, and sent to both L and R.
REVERB SEND 0–127 Adjusts the amount of audio sent to reverb.
DELAY
0.0–500msec
(0–25.0/29.9frame)
Adjusts the delay time of the audio.
Eect Outputs audio with a delay.
EFFECT PRESET
Species an eect preset (high-pass lter, noise gate, de-esser, compressor, and equalizer).
* When you change an eect preset, the settings of each eect are overwritten.
DEFAULT For line input (default setting)
MEETING For meetings
INTERVIEW For interviews
AMBIENT MIC For capturing ambient sound
HIGH PASS FILTER 80Hz OFF, ON
Turns the high-pass lter on/o.
Eect Cuts o unneeded low-band audio. The cuto frequency is 80 Hz.
NOISE GATE OFF, ON
Turns the noise gate on/o.
Eect
Eliminates audio that is lower than the specied threshold level. This is eective when
the noise that you want to remove is separate from the audio that you want to keep,
and can be used to remove hiss or other noise that is heard during periods of silence.
THRESHOLD -80– -48–0dB
Species the level used as the threshold for removing audio. Audio below the level set here is
removed.
RELEASE 30–500–5000ms Adjusts the length of time until the audio is fully attenuated after audio falls below the threshold.
DE-ESSER OFF, ON
Turns the de-esser on/o.
Eect
Reduces sibilant noise (the sounds you hear when pronouncing “s” words and other
hissing sounds).
SENS 0–80–100
Adjusts the sensitivity with which sibilants are detected.
DEPTH 0–64–100
Adjusts the intensity of the eect.
COMPRESSOR OFF, ON
Turns the compressor on/o.
Eect
Audio that exceeds the specied threshold level is compressed. This reduces the
dierence between the maximum volume and minimum volume, making the audio
more comfortable for listening.
THRESHOLD -50– -8–0dB
Species the level used as the threshold at which the compressor is applied. Compression is
applied to audio that exceeds the threshold.
RATIO
1.00 : 1, 1.12 : 1, 1.25 : 1, 1.40 : 1,
1.60 : 1, 1.80 : 1, 2.00 : 1, 2.50 : 1,
3.20 : 1, 4.00 : 1, 5.60 : 1, 8.00 : 1,
16.0 : 1, INF : 1
Species the degree of compression applied to the audio. The state in which no compression is
applied is dened as “1.”
ATTACK 0.0–30–100ms Species the time until compression starts when audio exceeding the threshold is input.
RELEASE 30–250–5000ms Adjusts the length of time until compression ends after audio falls below the threshold.
MAKEUP GAIN -40–0–40dB Adjusts the nal output volume level after applying the compressor.
EQUALIZER OFF, ON
Turns the equalizer on/o.
Eect Adjusts the volume for each frequency band.
Hi GAIN -15.0–0.0–15.0dB Boosts or attenuates the high band.
Hi FREQUENCY 1.0–10.0–20.0kHz Adjusts the center frequency when changing the volume in the high band.
Mid GAIN -15.0–0.0–15.0dB Boosts or attenuates the middle band.
Mid FREQUENCY 20.0Hz–500Hz–20.0kHz Adjusts the center frequency when changing the volume in the middle band.
Mid Q 0.5–1.0–16.0 Adjusts the width of the frequency band when boosting or attenuating the middle band.
Lo GAIN -15.0–0.0–15.0dB Boosts or attenuates the low band.
Lo FREQUENCY 20.0Hz–500Hz–20.0kHz Adjusts the center frequency when changing the volume in the low band.
MUTE/SOLO
Adjusts the mute/solo function for the input audio.
* This menu is derived from the “INPUT MUTE” and “SOLO” items in each input audio menu. The settings work in conjunction
with each other.
INPUT 1–4 MUTE OFF, ON
Turns the mute function on/o. If this is “ON,” the input audio is temporarily silenced.
If the mute function is assigned to the [DSK PVW] or [DSK ON] button, you can also switch this
by pressing the button.
AUDIO IN 1, 2 MUTE OFF, ON
LINE IN MUTE OFF, ON
MIC/AUX IN MUTE OFF, ON
INPUT 1–4 SOLO OFF, ON
Turns the solo function on/o. Only the audio for which this is “ON” is heard in the headphones.
* The solo function applies to the headphone output. It does not aect output other than the
headphones.
AUDIO IN 1, 2 SOLO OFF, ON
LINE IN SOLO OFF, ON
MIC/AUX IN SOLO OFF, ON
SOLO CLEAR ENTER Turns all solo settings o at once.
