Roland V-1HD+ - Appendices; Main Specifications

65
Main Specications
9 Video
Video Processing 4:2:2 (Y/Pb/Pr), 8-bit
Input Connectors
INPUT 1–3
HDMI type A x 3
* HDCP supported
INPUT 4
HDMI type A
* HDCP and multi-format supported
Output Connectors OUTPUT 1, 2 HDMI type A x 2
Input formats
INPUT 1–3
SYSTEM FORMAT setting: 720p SYSTEM FORMAT setting: 1080i or 1080p
FRAME RATE setting FRAME RATE setting
59.94 Hz 50 Hz 59.94 Hz 50 Hz
720/59.94p 720/50p 1080/59.94i 1080/29.97p 1080/50i
720/60p 1080/60i 1080/30p 1080/50p
1080/59.94p 1080/23.98p 1080/25p
1080/60p 1080/24p 1080/23.98p
1080/24p
* The input interlaced video signal is converted to progressive video signal by internal processing.
INPUT 4
FRAME RATE setting
59.94 Hz 50 Hz
480/59.94i 576/50i
480/59.94p 576/50p
720/59.94p 720/50p
720/60p 1080/50i
1080/59.94i 1080/29.97p 1080/50p
1080/60i 1080/30p 1080/25p
1080/59.94p 1080/23.98p 1080/23.98p
1080/60p 1080/24p 1080/24p
VGA (640 x 480/60 Hz) VGA (640 x 480/60 Hz)
SVGA (800 x 600/60 Hz) SVGA (800 x 600/60 Hz)
XGA (1024 x 768/60 Hz) XGA (1024 x 768/60 Hz)
WXGA (1280 x 800/60 Hz) WXGA (1280 x 800/60 Hz)
SXGA (1280 x 1024/60 Hz) SXGA (1280 x 1024/60 Hz)
FWXGA (1366 x 768/60 Hz) FWXGA (1366 x 768/60 Hz)
SXGA+ (1400 x 1050/60 Hz) SXGA+ (1400 x 1050/60 Hz)
UXGA (1600 x 1200/60 Hz) UXGA (1600 x 1200/60 Hz)
WUXGA (1920 x 1200/60 Hz) WUXGA (1920 x 1200/60 Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60 Hz: Reduced blanking
* The input interlaced video signal is converted to progressive video signal by internal processing.
Still Image
Bitmap le (.bmp): Maximum 1920 x 1080 pixels, 24-bit color, uncompressed
PNG le (.png): Maximum 1920 x 1080 pixels, 24-bit color
* It can be stored up to 4 les in the internal memory.
* PNG alpha channel not supported
Output formats OUTPUT 1, 2
SYSTEM FORMAT
setting
FRAME RATE setting
59.94 Hz 50 Hz
720p 720/59.94p 720/50p
1080i 1080/59.94i 1080/50i
1080p 1080/59.94p 1080/50p
Video Eects
Transition CUT, MIX (DISSOLVE/FAM/NAM), WIPE (8 types)
Composition
PinP (SQUARE, CIRCLE, DIAMOND), SPLIT (2 types), Keyer (Luminance key, Chroma key)
DSK (Luminance key, Chroma key)
Other
Flip horizontal, Flip vertical, Still image capture, Still image playback
Output fade (Audio, Video: WHITE or BLACK), Test pattern output
