Roland V-1HD+ - Page 66

66
Appendices
9 Audio
Sample rate 24 bits/48 kHz
Audio formats Linear PCM, 24 bits/48 kHz, 2 ch
Input Connectors
INPUT 1–4 HDMI Type A x 4
AUDIO IN 1–2 XLR-3-31 type (balanced, phantom power DC 48 V, 14 mA Max)
LINE IN RCA phono type
MIC/AUX IN Stereo miniature phone type (PLUG-IN power)
Output Connectors
OUTPUT 1–3 HDMI Type A x 2
AUDIO OUT L, R 1/4-inch TRS phone type
PHONES Stereo miniature phone type
Nominal Input Level
AUDIO IN 1–2 -60 to +4 dBu (Maximum input level: +24 dBu)
LINE IN -10 dBu (Maximum input level: +10 dBu)
MIC/AUX IN -51 to -10 dBu (Maximum input level: +10 dBu)
Input Impedance
AUDIO IN 1–2 10 kΩ
LINE IN 15 kΩ
MIC/AUX IN 10 kΩ
Nominal Output Level
AUDIO OUT L, R +4 dBu (Maximum output level: +24 dBu)
PHONES 72 mW + 72 mW (32 Ω load)
Output Impedance
AUDIO OUT L, R 600 Ω
PHONES 10 Ω
Audio Eects Delay, High pass lter, De-esser, Compressor, Noise gate, Equalizer, Limiter, Reverb, Test tone output
9 Others
Other Connectors
USB MEMORY USB A type (for USB ash drive)
USB USB B type (for remote control)
RS-232 DB-9 type (male, for remote control)
TALLY DB-9 type (female, for TALLY output)
Other Functions Preset memory (8 types), Panel lock function, EDID emulator, Auto switching, Auto input detect
Power Supply AC Adaptor
Current Draw 2.1 A
Power Consumption 25.2 W
Operation Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
316 (W) x 121 (D) x 65 (H) mm
12-1/2 (W) x 4-13/16 (D) x 2-9/16 (H) inches
Weight
(excluding AC adaptor)
1.4 kg
3 lbs 2 oz
Accessories Startup Guide, Leaet “USING THE UNIT SAFELY,” AC adaptor, Power cord
* 0 dBu = 0.775 Vrms
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the Roland website.
