Roland V-1HD+ - 17: SYSTEM Menu Options

58
Menu List
16: TALLY/RS-232
Menu item Value (bold text: default value) Explanation
TALLY OFF, ON
Turns the tally signal output on/o. If this is “ON,” , the tally signal is output from the TALLY
connector (p. 67).
RS-232 OFF, ON If this is “ON,” RS-232 commands can be transmitted and received.
RATE 38400, 115200 Species the communication speed (bps) of the RS-232 connector.
17: SYSTEM
Menu item Value (bold text: default value) Explanation
HDCP (*17) OFF, ON
Species whether HDCP is enabled or disabled. If this is “ON,” copyright-protected (HDCP) video
can be input. HDCP is also added to the video that is output.
FRAME RATE (*17) 59.94, 50Hz Species the frame rate.
SYSTEM FORMAT (*17) 1080p, 1080i, 720p
Species the system format.
* The output format is the same as the system format.
CUT SW ASSIGN (*18)
Species the function of the [CUT] button.
H
AUTO TAKE
When the video of the B/PST bus is selected, switches to the video of the A/PGM bus. The
transition time is specied by the TRANSITION TIME menu item “WIPE/MIX TIME.”
H
AUTO TAKE
I
Switches the video between A/PGM bus and B/PST bus. The transition time is specied by the
TRANSITION TIME menu item “WIPE/MIX TIME.”
H
CUT
When the video of the B/PST bus is selected, switches to the video of the A/PGM bus as a cut.
H
CUT
I
Switches the video between A/PGM bus and B/PST bus as a cut.
H
TRANSFORM
When the video of the B/PST bus is selected, switches to the video of the A/PGM bus as a cut only
while you’re holding down the button.
AUTO SW ASSIGN (*18)
Species the function of the [AUTO] button.
AUTO TAKE
I
When the video of the A/PGM bus is selected, switches to the video of the B/PST bus. The
transition time is specied by the TRANSITION TIME menu item “WIPE/MIX TIME.”
H
AUTO TAKE
I
Switches the video between A/PGM bus and B/PST bus. The transition time is specied by the
TRANSITION TIME menu item “WIPE/MIX TIME.”
CUT
I
When the video of the A/PGM bus is selected, switches to the video of the B/PST bus as a cut.
H
CUT
I
Switches the video between A/PGM bus and B/PST bus as a cut.
TRANSFORM
I
When the video of the A/PGM bus is selected, switches to the video of the B/PST bus as a cut only
while you’re holding down the button.
PANEL OPERATION
Species the operation mode for video transitions.
A/B The video of the bus toward which the video fader is slided becomes the nal output.
PGM/PST
The video on the A/PGM bus is always the nal output. Select the preview output video (the
video to be output next) for the B/PST bus side.
PANEL LOCK
ENTER Displays the PANEL LOCK menu.
Enable (ON) or disable (OFF) the panel lock.
Menu item Value (bold text: default value) Explanation
ALL SW & VOLUME OFF, ON The following settings are turned on/o together.
A/PGM 1–4 SW OFF, ON A/PGM cross-point [1]–[4] buttons
B/PST 1–4 SW OFF, ON B/PST cross-point [1]–[4] buttons
CUT SW OFF, ON [CUT] button
AUTO SW OFF, ON [AUTO] button
1/5–4/8 SW OFF, ON [1/5]–[4/8] buttons
MODE SW OFF, ON [MODE] button
TRANSITION SW OFF, ON [TRANSITION] button
VIDEO FADER OFF, ON Video fader
PinP SW OFF, ON [PinP] button
SPLIT SW OFF, ON [SPLIT] knob
CONTROL KNOB OFF, ON [CONTROL 1] [CONTROL 2] knobs
DSK PVW SW OFF, ON [DSK PVW] button
DSK ON SW OFF, ON [DSK ON] button
OUTPUT FADE OFF, ON [OUTPUT FADE] knob
AUDIO LEVEL OFF, ON [AUDIO IN 1] [AUDIO IN 2] [LINE IN] [MAIN] knobs
AUDIO GAIN OFF, ON [AUDIO GAIN 1] [AUDIO GAIN 2] knobs
SETUP (LINK) SW OFF, ON [SETUP] button
LIMITER SW OFF, ON [LIMITER] button
(*17) A change in the setting is not applied until you press the [VALUE] knob to conrm.
(*18) This can be set if “PANEL OPERATION” is “A/B.”
