RS-232 Command Reference
Other operations
Item
Sent
command
Response
command
Parameter
Select functions for buttons
[1/5]–[4/8]
stxMOD:a; ack a = 0 (STILL IMAGE), 1 (PinP SOURCE), 2 (MEMORY 1–4), 3 (MEMORY 5–8),
Press button [1/5]–[4/8] stxMNS:a; ack a = 0 (1/5)–3 (4/8)
Set HDCP on/o stxHCP:a; ack a = 0 (OFF), 1 (ON)
Recall preset memory stxMEM:a; ack a = 0 (1), 1 (2), 2 (3), 3 (4), 4 (5), 5 (6), 6 (7), 7 (8)
Set the fade-in time for the inset
screen when recalling a memory
stxPFT:a; ack a = 0 (0.0sec)–10 (1.0sec)
Set test pattern stxTPT:a; ack a = 0 (OFF), 1 (75% COLOR BAR), 2 (100% COLOR BAR), 3 (RAMP), 4 (STEP)
5 (HATCH)
Set test tone stxTTN:a; ack a = 0 (OFF), 1 (-20dB@1kHz: 1kHz), 2 (-10dB@1kHz: 1kHz), 3 (0dB@1kHz: 1kHz)
4 (-20dB@1kHz: 500Hz), 5 (-10dB@1kHz: 500Hz), 6 (0dB@1kHz: 500Hz)
Retrieve status of controls stxQPL:a; stxQPL:b; Send command parameters
a = 0 (PGM/A), 1 (PST/B), 2 (MODE 1/5–4/8), 3 (MODE), 4 (TRANSITION), 5 (SPLIT)
6 (PinP), 7 (DSK PVW), 8 (DSK ON), 9 (LIMITER), 10 (LINK), 11 (Video fade level)
12 (ALL)
Response command parameters
a = 0, b = 0 (INPUT 1)–4 (INPUT 4) A/PGM cross-point buttons
a = 1, b = 0 (INPUT 1)–4 (INPUT 4) PST/B cross-point buttons
a = 2, b = 0 (1/5)–4 (4/8) [1/5]–[4/8] buttons
a = 3, b = 0 (STILL IMAGE) [MODE] button
1 (PinP SOURCE)
2 (MEMORY 1–4)
3 (MEMORY 5–8)
a = 4, b = 0 (MIX), 1 (WIPE) [TRANSITION] button
a = 5, b = 0 (O ), 1 (On) [SPLIT] button
a = 6, b = 0 (O ), 1 (On) [PinP] button
a = 7, b = 0 (O), 1 (On) Preview output of the DSK compositing result
a = 8, b = 0 (O ), 1 (On) DSK composition
a = 9, b = 0 (O ), 1 (On) [LIMITER] button
a = 10, b = 0 (O), 1 (On) [SETUP] button (stereo link function)
a = 11, b = 0–2047
a = 12, b = returns all information described above.
(Example) stxQPL:0,3,2,1,1,0,0,0,0,0,0;
Retrieve output status of INPUT 1–4 stxTLY; stxTLY:a,b,c,d; a–d = 0 (Dark), 1 (Red: nal output), 2 (Green: preview output)
This returns the output status for INPUT 1–4.
(Example) stxTLY:1,2,0,0;
Acquire status of the unit stxACS; ack
Version information stxVER; VER:V-1HD PLUS,a; a = Version number
* The version info is ASCII text strings.
Flow control XON
Flow control XOFF
Commands spontaneously sent from this unit
Item
Sent
command
Response
command
Parameter
Error detected stxERR:a; a = 0 (Syntax error) The received command contains an error.
5 (Out of range error) A parameter of the received command is out of range.
Flow control XON
Flow control XOFF
