Rosemount 3051S - Section 2 Configuration

3
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
Section 2 Configuration
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Engineering Assistant installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Flow configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Basic device configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 24
Detailed device configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 27
Variable configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 38
Menu trees and Field Communicator Fast Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 57
2.1 Overview
This section contains information for configuring the flow and device configuration for the Rosemount
™
3051S MultiVariable
™
Transmitter (Rosemount 3051SMV). Engineering Assistant installation and Flow
configuration instructions apply to Engineering Assistant version 6.3 or later. Basic device configuration,
Detailed device configuration, and Variable configuration are shown for AMS Device Manager version 9.0
or later, but also include Fast Key sequences for Field Communicator version 2.0 or later. Engineering
Assistant and AMS Device Manager screens are similar and follow the same instructions for use and
navigation. For convenience, Field Communicator Fast Key sequences are labeled “Fast Keys” for each
software function below the appropriate headings. The functionality of each host as show in Ta bl e 2 -1 :
Note
Coplanar transmitter configurations measuring gage pressure and process temperature (measurement
5) will report as the pressure as differential pressure. This will be reflected on the LCD display, nameplate,
digital interfaces, and other user interfaces.
Table 2-1. Host Functionality
• Available
— Not available
Multivariable
type
Functionality
Rosemount 3051SMV
Engineering Assistant
AMS Device
Manager
Field
Communicator
Fully
compensated
mass and energy
flow (M)
Flow Configuration
• • —
Device Configuration
• • •
Test Calculation
• • •
Calibration
• • •
Diagnostics
• • •
Direct process
variable output
(P)
Device Configuration
— • •
Calibration
— • •
Diagnostics
— • •
