31
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
2.6.3 Variable mapping
The Variable Mapping tab is used to define which process variable will be mapped to each HART variable.
The primary variable represents the 4–20 mA analog output signal while the 2nd, 3rd, and 4th variables
are digital. To edit the variable assignments, select the appropriate process variables from the
drop-down menus and select Apply.
Figure 2-21. Device - Variable Mapping Tab
Mass and energy flow Fast Keys
1, 4, 3, 4
Direct process variable output Fast Keys
1, 4, 3, 4
