18
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
Sending a saved configuration
1. To send a saved configuration, open Engineering Assistant in offline mode and select File>Open.
2. Navigate to the saved .smv file to be sent. Select Open.
3. The Engineering Assistant Device Connection screen will appear, see Figure 2-12 on page 17.
4. Select the Search button located in the lower right corner of the screen. Engineering Assistant will
begin to search for connected devices.
5. When the search is completed, select the device to communicate with and select Send
Configuration button.
6. Once the configuration is finished being sent to the device, a notification appears.
7. If finished with the configuration process, close Engineering Assistant.
2.4.9 Other fluid configurations
Natural gas AGA No. 8 detail characterization or ISO 12213, molar
composition flow configuration
1. Expand the Gas category.
2. Expand the Natural Gas category.
3. Select AGA Report No. 8 Detail Characterization Method or ISO 12213, Molar Composition
Method.
4. Select Next > to proceed to the Fluid Composition tab. Figure 2-13 shows an example of the Fluid
Composition tab for AGA Report No. 8 Detail Characterization Method. The ISO 12213, Molar
Composition Method Fluid Composition tab will require the same information.
Figure 2-13. Fluid Composition Tab
