Rosemount 3051S - Functional Specifications; A.1.2 Functional Specifications

Specifications and Reference Data
129
Specifications and Reference Data
September 2017
Reference Manual
00809-0100-4803, Rev GA
Mounting position effects
Vibration effect
Less than ±0.1% of URL when tested per the requirements of
IEC60770-1 field or pipeline with high vibration level(10–60
Hz 0.21mm displacement peak amplitude/60–2000 Hz 3g).
For housing style codes 1J, 1K, and 1L:
Less than ±0.1% of URL when tested per the requirements of
IEC60770-1 field with general application or pipeline with
low vibration level (10–60 Hz 0.15mm displacement peak
amplitude/
60–500 Hz 2g).
Power supply effect
Less than ±0.005% of calibrated span per volt change in
voltage at the transmitter terminals
Transient protection (Option T1)
Meets IEEE C62.41.2-2002, location category B
6 kV crest (0.5 μs - 100 kHz)
3 kA crest (8 ⫻ 20 microseconds)
6 kV crest (1.2 ⫻ 50 microseconds)
Meets IEEE C37.90.1-2002 surge withstand capability
SWC 2.5 kV crest, 1.0 MHz wave form
A.1.2 Functional specifications
Range and sensor limits
Rosemount models Ultra, Ultra for Flow, Classic, and Classic MV
3051SMV_ _ 1, 2 DP:
AP/GP:
Zero shifts up to ±1.25 inH
2
O (3,11 mbar), which can be zeroed; no span effect
Zero shifts to ±2.5 inH
2
O (6,22 mbar), which can be zeroed; no span effect
3051SMV_ _ 3, 4 Zero shifts up to ±1.25 inH
2
O (3,11 mbar), which can be zeroed; no span effect
Electro Magnetic Compatibility (EMC)
(1)
Meets all relevant requirements of EN 61326 and NAMUR NE-21.
1. Requires shielded cable for both temperature and loop wiring.
Table A-1. Rosemount 3051SMV Differential Pressure Range and Sensor Limits
Range
Minimum span Range limits
Ultra and Ultra for Flow Classic and classic MV Upper (URL) Lower (LRL)
(1)
1. Lower (LRL) is 0 inH
2
O (0 mbar) for Ultra for Flow.
0 0.1 inH
2
O (0,25 mbar) 0.1 inH
2
O (0,25 mbar) 3.0 inH
2
O (7,5 mbar) –3.0 inH
2
O (–7,5 mbar)
1 0.5 inH
2
O (1,24 mbar) 0.5 inH
2
O (1,24 mbar) 25.0 inH
2
O (62,3 mbar) –25.0 inH
2
O (–62,3 mbar)
2 1.3 inH
2
O (3,11 mbar) 2.5 inH
2
O (6,23 mbar) 250.0 inH
2
O (0,62 bar) –250.0 inH
2
O (–0,62 bar)
3 5.0 inH
2
O (12,4 mbar) 10.0 inH
2
O (24,9 mbar) 1000.0 inH
2
O (2,49 bar) –1000.0 inH
2
O (–2,49 bar)
4 1.5 psi (103,4 mbar) 3.0 psi (206,8 mbar) 300.0 psi (20,7 bar)
(2)
2. For measurement type 1 and 2, URL = 150.0 psi (10,34 bar) and LRL = –150.0 psi (10,34 bar).
–300.0 psi (–20,7 bar)
(2)
5 10.0 psi (689,5 mbar) 20.0 psi (1,38 bar) 2000.0 psi (137,9 bar) – 2000.0 psi (–137,9 bar)
