Introduction
September 2017
Introduction
Section 1 Introduction
1.1 Using this manual
The sections in this manual provide information on installing, operating, and maintaining the
Rosemount
™
3051S MultiVariable
™
Transmitter (Rosemount 3051SMV). The sections are organized as
follows:
Section 2: Configuration provides instruction on commissioning and operating Rosemount 3051SMV.
Information on software functions, configuration parameters, and online variables is also included.
Section 3: Installation contains mechanical and electrical installation instructions.
Section 4: Operation and Maintenance contains operation and maintenance techniques.
Section 5: Troubleshooting provides troubleshooting techniques for the most common operating
problems.
Section 6: Safety Instrumented Systems Requirements contains identification, commissioning,
maintenance, and operations information for the Rosemount 3051S MultiVariable Safety
Instrumented System (SIS) Safety Transmitter.
Appendix A: Specifications and Reference Data supplies reference and specification data, as well as
ordering information.
Appendix B: Product Certifications contains intrinsic safety approval information, European ATEX
directive information, and approval drawings.
Models covered
The following Rosemount 3051SMV Transmitters are covered in this manual:
Table 1-1. Rosemount 3051SMV Measurement with Fully Compensated Mass and Energy Flow
Output
Measurement type Multivariable type - M
1 Differential pressure, static pressure, temperature
2 Differential pressure and static pressure
3 Differential pressure and temperature
4 Differential pressure
Table 1-2. Rosemount 3051SMV Measurement with Direct Process Variable Output
Measurement type Multivariable type - P
1 Differential pressure, static pressure, temperature
2 Differential pressure and static pressure
3 Differential pressure and temperature
5 Coplanar static pressure and temperature
6 In-line static pressure and temperature
