24
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
2.5 Basic device configuration
This section provides procedures for configuring the basic requirements to commission the Rosemount
3051SMV. The Basic Setup tab, shown in Figure 2-18 on page 25, can be used to perform all of the
required transmitter configuration. The complete list of Field Communicator Fast Keys for basic setup are
shown in Table 2-13 on page 62 and Table 2-14 on page 63.
Based on the configuration ordered, some measurements (i.e. static pressure, process temperature)
and/or calculation types (i.e. mass, volumetric, and energy flow) may not be available for all fluid types.
Available measurements and/or calculation types are determined by the multivariable type and
measurement type codes ordered. See “Ordering information” on page 138 for more information.
All screens in this section are shown for multivariable type M (fully compensated mass and energy flow)
with measurement type 1 (differential pressure, static pressure, and process temperature). Field
Communicator Fast Keys are given for both multivariable type M and P (direct process variable output)
with measurement type 1. Field Communicator Fast Keys and screens for other multivariable types and
measurement types may vary.
Note
All screen shots in this section will be shown using AMS Device Manager. Engineering Assistant screens
are similar and the instructions shown here apply to both AMS Device Manager and Engineering
Assistant.
When using Engineering Assistant, a Reset Page button will be shown. In online mode, the Reset Page
button will return all values on tab to the initial values received from the device before the start of the
configuration. If editing a previously saved configuration, the Reset Page button will return all values on
tab to those that were last saved. If starting a new configuration, all entered values on tab will be erased.
When information is edited on any AMS Device Manager tab, it will be highlighted in yellow. Edited
information is not sent to the transmitter until the Apply or OK button is selected.
Units of measure
If a unit of measure is edited and the Apply button is selected, the unit of measure will be changed in the
device memory and on screen, but the value may take up to 30 seconds to be updated on the AMS
Device Manager screen.
Mass and energy flow Fast Keys
1, 3
Direct process variable output Fast Keys
1, 3
