Specifications and Reference Data
September 2017
Reference Manual
00809-0100-4803, Rev GA
Specifications and Reference Data
128
Ambient temperature effect
Rosemount
models
Ultra
per 50 °F (28 °C)
Classic or Classic MV
per 50 °F (28 °C)
Ultra for Flow
(1)
–40 to 185 °F (–40 to 85 °C)
3051SMV_ _1: Differential pressure, static pressure, and temperature
3051SMV_ _2: Differential pressure and static pressure
DP Ranges 2–3 N/A ± (0.0125% URL + 0.0625% span)
from 1:1 to 5:1;
± (0.025% URL + 0.125% span) for
> 5:1
±0.13% reading up to 8:1 DP turndown
from URL;
±(0.13 + 0.0187 [URL/RDG
(3)
])% reading
to 100:1 DP turndown from URL
DP Range 1 N/A ± (0.1% URL + 0.25% Span)
from 1:1 to 50:1
N/A
AP and GP N/A ± (0.0125% URL + 0.0625% span)
from 1:1 to 10:1;
± (0.025% URL + 0.125% span) for
>10:1
± (0.009% URL + 0.025% span)
from 1:1 to 10:1;
± (0.018% URL + 0.08% span)
for > 10:1
3051SMV_ _ 3: Differential pressure and temperature
3051SMV_ _ 4: Differential pressure
Range 2–5
(2)
± (0.009% URL + 0.025% span)
from 1:1 to 10:1;
± (0.018% URL + 0.08% span)
from >10:1 to 200:1
± (0.0125% URL + 0.0625% span)
from 1:1 to 5:1;
± (0.025% URL + 0.125% span)
from >5:1 to 100:1
±0.13% reading up to 8:1 DP turndown
from URL;
±(0.13 + 0.0187 [URL/RDG
(3)
])% reading
to 100:1 DP turndown from URL
Range 0 ± (0.25% URL + 0.05% span)
from 1:1 to 30:1
± (0.25% URL + 0.05% span)
from 1:1 to 30:1
N/A
Range 1 ± (0.1% URL + 0.25% span)
from 1:1 to 50:1
± (0.1% URL + 0.25% span)
from 1:1 to 50:1
N/A
Process Temp.
RTD Interface
(4)
N/A ±0.39 °F (0,216 °C)
per 50 °F (28 °C)
±0.39 °F (0,216 °C)
per 50 °F (28 °C)
1. Ultra for Flow is only available for Rosemount 3051SMV DP Ranges 2–3.
2. Use classic specification for Rosemount 3051SMV DP Range 5 Ultra.
3. RDG refers to transmitter reading.
4. Specifications for process temperature are for the transmitter portion only. The transmitter is compatible with any Pt 100 (100 ohm platinum) RTD. Examples of
compatible RTDs include Rosemount Series 68 and 78 RTD Temperature Sensors.
Line Pressure effect
(1)
Models
(1)
Ultra and Ultra for Flow Classic and Classic MV
Rosemount 3051SMV: Differential pressure measurement only
Zero error
(2)
Range 2–3
Range 0
Range 1
± 0.025% URL per 1000 psi (69 bar)
± 0.125% URL per 100 psi (6,89 bar)
± 0.25% URL per 1000 psi (69 bar)
± 0.05% URL per 1000 psi (69 bar)
± 0.125% URL per 100 psi (6,89 bar)
± 0.25% URL per 1000 psi (69 bar)
Span error
(3)
Range 2–3
Range 0
Range 1
± 0.1% of reading per 1000 psi (69 bar)
± 0.15% of reading per 100 psi (6,89 bar)
± 0.4% of reading per 1000 psi (69 bar)
± 0.1% of reading per 1000 psi (69 bar)
± 0.15% of reading per 100 psi (6,89 bar)
± 0.4% of reading per 1000 psi (69 bar)
1. For zero error specifications for line pressures above 2000 psi (137,9 bar) or line pressure effect specifications for DP Ranges 4–5, see the Rosemount 3051SMV
Reference Manual
.
2. Zero error can be zeroed.
3. Specifications for option code P0 are two times those shown above.
