Figure 2-42. Menu Tree for Fully Compensated Mass and Energy Flow
1. Device Setup 2. PV 3. AO 4. PV LRV 5. PV URV
1. Process Variables...........................2. Diagnostics and Service............................... 3. Basic Setup....................4. Detailed Setup........... 5. Review
1. Flow Rate
2. Energy Rate
3. Totalizer
4. Diff. Pressure
5. Absolute Pressure
6. Gage Pressure
7. Process Temp.
8. Module Temp.
9. Analog Output
10.Percent of Range
11.Primary Variable is
1. Reading
2. Status
1. Status
2. Loop Test
3. Test Flow Calc
4. Configure Fixed
Variables
5. Calibration
1. Diff. Pressure
2. Static Pressure
3. Process Temp.
1. Rerange
2. Analog
Output
Trim
3. Diff.
Pressure
Trim
4. Static
Pressure
Trim
5. Process
Temp.
Trim
1. Upper Range Value
2. Lower Range Value
1. Digital-to-Analog
Tri m
2. Scaled
Digital-to-Analog
Tri m
3. Recall Factory Trim
1. Zero Trim
2. Lower Sensor Trim
3. Upper Sensor Trim
4. Sensor Trim
Calibration Type
5. Sensor Trim Points
6. Recall Factory Trim
1. Lower Sensor Trim
2. Upper Sensor Trim
3. Sensor Trim Points
4. Callendar Van
Dusen
5. Recall Factory Trim
1. Configure
Coefficients
2. Reset Coefficients
3. Process Temp.
1. Tag
2. Long Tag
3. Units
4. Range
Value
5. Device
Info
6. Transfer
Function
7. Damping
8. LCD
Display
Config.
1. Flow Rate
2. Energy Rate
3. Totalizer
4. Differential
Pressure
5. Absolute Pressure
6. Gage Pressure
7. Process Temp.
8. Module Temp.
1. Upper Range
Value
2. Lower Range Value
1. Date
2. Descriptor
3. Message
4. Write Protect
5. Model
6. Model Number I
7. Model Number II
8. Model Number III
9. Model Number IV
1. Flow Rate
2. Energy Rate
3. Differential
Pressure
4. Static Pressure
5. Process
1. Zero Trim
2. Lower Sensor Trim
3. Upper Sensor Trim
4. Sensor Trim
Calibration Type
5. Sensor Trim Points
6. Recall Factory Trim
