Figure 2-43. Menu Tree for Direct Process Variable Output
1. Device Setup 2. PV 3. AO 4. PV LRV 5. PV
1. Process Variables...........................2. Diagnostics and Service............................. 3. Basic Setup......................4. Detailed Setup..........5. Review
1. Diff. Pressure
2. Absolute Pressure
3. Gage Pressure
4. Process Temp.
5. Module Temp.
6. Analog Output
7. Percent of Range
8. Primary Variable is
1. Reading
2. Status
1. Status
2. Loop Test
3. Configure Fixed
Variables
4. Calibration
1. Diff. Pressure
2. Static Pressure
3. Process Temp.
1. Rerange
2. Analog
Output
Trim
3. Diff.
Pressure
Trim
4. Static
Pressure
Trim
5. Process
Temp.
Trim
1. Upper Range Value
2. Lower Range Value
1. Digital-to-Analog
Tri m
2. Scaled
Digital-to-Analog
Tri m
1. Zero Trim
2. Lower Sensor Trim
3. Upper Sensor Trim
4. Sensor Trim
Calibration Type
5. Sensor Trim Points
6. Recall Factory Trim
1. Lower Sensor Trim
2. Upper Sensor Trim
3. Sensor Trim Points
4. Callendar Van
Dusen
1. Configure
Coefficients
2. Reset Coefficients
1. Tag
2. Long Tag
3. Units
4. Range
Value
5. Device
Info
6. Transfer
Function
7. Damping
8. LCD
Display
Config.
1. Differential
Pressure
2. Absolute Pressure
3. Gage Pressure
4. Process Temp.
5. Module Temp.
1. Upper Range
Value
2. Lower Range Value
1. Date
2. Descriptor
3. Message
4. Write Protect
5. Model
6. Model Number I
7. Model Number II
8. Model Number III
9. Model Number IV
1. Differential
Pressure
2. Static Pressure
3. Process
Temperatu re
1. Zero Trim
2. Lower Sensor Trim
3. Upper Sensor Trim
4. Sensor Trim
Calibration Type
5. Sensor Trim Points
6. Recall Factory Trim
