Rotax 915 i A SERIES - Checking the Compression

BRP-Rotax
MAINTENANCE MANUAL
CHECKING THE COMPRESSION
General note
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded!
Figure 7.2: Checking the compression. TYPICAL
1
Adaptor
2
Manometer/Test gauges set
3
Orifice jet
4
Compressor
12–20–00
Page 8
December 01 2017
Effectivity: 915 i A Series
Edition 0/Rev. 0
