Rotax 915 i A SERIES Maintenance Manual

BRP-Rotax
MAINTENANCE MANUAL
INSTALLATION OF PROPELLER GEARBOX
Preparation
ATTENTION
No hammering or pressing! The drive gear must only be pushed on manually.
ATTENTION
Ensure that the friction washer is in the correct installation position.
ATTENTION
The dog and drive gears are in pairs.
Only use parts with the same serial number.
• Clean and degrease all parts carefully.
• Remove LOCTITE adhesive residue with LOCTITE 7063.
• Visual inspection of the crankshaft on the power take off side.
Figure 5.6
1
Crankshaft (power take off side)
2
Drive gear
3 Friction washer VS-30 4 Hex. nut
Step
Procedure
1
Push the drive gear onto the crankshaft.
05–50–00
Page 8
December 01 2017
Effectivity: 915 i A Series
Edition 0/Rev. 0
