BRP-Rotax
MAINTENANCE MANUAL
FUEL SYSTEM
Figure 7.10: Overview
1 Fuel rail 2/4 outline line 2 Fuel rail 1/3 feed line
3 Fuel rail 4
Fuel hose assy.
5
Fuel injector
6
Pressure regulator
12–20–00
Page 22
December 01 2017
Effectivity: 915 i A Series
Edition 0/Rev. 0
