5- Information / Configuration
Page 5-52 F@ST 4310 Reference Manual
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Proceed as follows:
• Select the required WAN interface in the Use Interface list.
• Check the Select a Service box, then select the service of your choice from the scroll down list, for
example "SNMP".
The External Port Start, External Port End, Internal Port Start, Internal Port End and Protocol
fields (transport protocol associated with this service) are automatically filled in the table.
or
• Check the Custom Service box, enter the name of the server you want to connect to, then:
- Complete the ID Host of your computer's IP address (this is attributed by your router's DHCP
server).
- Fill in the External Port Start, External Port End, Internal Port Start, Internal Port End and
Protocol fields.
A few rules for entering values:
• When you want to select a single port, the start port (External Port Start or Internal Port Start) and the
end port (External Port End or Internal Port End) must be identical.
• When you want to select a range of ports, the start port number must be lower than the end port number.
• You must always start entering with the External Port Start and External Port End ports.
• When you allocate a number to an External Port Start, the same number is automatically allocated to
the Internal Port Start and identically for External Port End.
The following diagram contains an example:
The "Delta Force 2" service is available on your computer via the external ports 3568 and 3569 (WAN side)
and via the internal ports 3568 and 3569 (LAN side).
Note
You may complete the table by adding other ports associated with a protocol.
