130 • Service Mode Programming Sam4s SPS-300 OP Manual v1.35
RS232C Port Options
At the S control lock position menu, press 8 for RS232 PORT programming. The
RS232 PORT selection screen displays:
RS232 PORT
1. RS232 PORT 1
2. RS232 PORT 2
3. RS232 PORT 3
4. RS232 PORT 4
Enter the digit (1-4) corresponding to the port you wish to program. The appropriate
PORT PROGRAM screen displays:
PORT 1 PROGRAM PG1
BAUD RATE 0
0:9600 1:1200 2:2400
3:4800 4:19200 5:38400
6:57600 7:115200
PARITY CHECK 0
0:NONE 1:ODD 2:EVEN
DATA BITS(0:8 1:7) 0
At each field, press CASH to view the selections. Enter the digit representing your
selection.
Press PAGE DOWN to view page 2 of the PORT PROGRAM:
PORT 1 PROGRAM PG2
STOP BITS(0:1 1:2) 0
DEVICE FUNCTION 0
-------------------------------
0:NONE 1:PC 2:SCL
3:RJ 4:RP 5:LIQUOR
6:SCAN 7:COIN 8:RESERVED
9:POLE 10:EFT 11:PDC
