32 • Getting Started Sam4s SPS-300 OP Manual v1.35
Clearing Memory
Before you use your SPS-300 Series ECR for the first time, you must perform a memory all
clear to ensure that all totals and counters are cleared and that the default program is installed.
CAUTION: The procedures described in this area are security sensitive. Clearing the SPS-
300 Series memory after the register is put into service will erase all programming as well as
totals and counters. Do not share this information with unauthorized users and distribute the key
marked “C” only to those you may want to perform these functions.
PRINTER SELECTION PROCEDURE NOTE: During the Memory All Clear sequence you
will be asked to indicate the printer configuration of the model you are using, i.e. Single Station
printer or 2-Station printer. Printer selection can also be done as a separate procedure: Power up
in S-Mode while holding the 00 (double zero) key. This procedure will not clear all memory, but
will reset the keyboard to its default key assignments.
AUTO CUTTER SELECTION: After the station printer selection, you will be prompted for
‘Auto Cut?’ There is no Auto-Cutter installed on terminals, select CLEAR for no cutter.
NOTE: Firmware versions v1.116 and later have EMV Integrated Payment capability. With
these versions, an SD Card is required for EMV operations. If not using EMV, press Clear to
bypass the ‘SD Card Required’ message.
SPS-320/SPS-340 Memory All Clear
1. Turn the power switch located on the right side of the register to the OFF position.
2. Turn the control lock to the S position.
3. Press and hold the key position where the CHECK key is located on the default
keyboard layout.
4. Continue to hold the appropriate key while turning the power switch to the ON
position. The message “RAM ALL CLEAR" displays.
5. Press the upper left key of the keyboard, then the lower left key, then the upper right
key, and finally press the lower right key.
1
3
2
4
SPS-320
SPS-340
SPS-320 and SPS-340
Press and hold the
CHECK key position
during power-up in S
mode.
To Next Page
