3 - 42 HS70A Service Manual
contrast of a DICOM image when saving it. The saved image can be viewed with any
PACS device that has DICOM VOI LUT implemented.
- Window Center: Enter a value for the DICOM Tag (0028, 1050) setting. The setting
value indicates the brightness of an image that is displayed by the storage service.
Relative to 128, a higher value results in a darker image. Note that this function can be
used only when it is supported by the storage service.
- Window Width: Enter a value for the DICOM Tag (0028, 1051) setting. The setting
value indicates the contrast of the image displayed by the storage service. Relative to
256, higher values result in lower contrast. Note that this function is available only
when it is supported by the storage service.
Maintain association
If Transfer Mode is set to ‘Send As You Go’ in Storage Service, you can configure
‘Maintain Association’.
- If the checkbox is selected: Even after image transfer has been completed, association
is maintained until End Exam is selected.
- If the checkbox is not selected: Association is terminated once the image has been
transferred.
Print Server Information
Select ‘PRINT’ under Services. Configure the Print Service using DICOM.
Color
Specify whether to use color for printing. Select Grayscale or RGB.
Format
Specify the paper layout. Select from 1x1, 1x2, 2x2, 2x3, 3x3, 3x4, 3x5, 4x4, 4x5, and
4x6.
Orientation
Specify the orientation of the paper. Select either Landscape or Portrait.
NOTE
You can configure a printer connected to the DICOM network only.
Depending on the printer, some of the following functions may not be
available. Before configuring the printer service, refer to the printer’s
user manual or its DICOM Conformance Statement.
To Next Page
