Sanyo PLC HF10000L User Manual

52
Video Input
This function returns all adjusted values to the factory default
settings. Press the SELECT button at Reset to display a
confirmation box. To reset, press the SELECT button at “Yes.”
Ceiling
Rear
When this function is set to On, the picture will be top/
bottom and left/right reversed. This function is used to
project the image from a ceiling-mounted projector.
When this function is set to On, the picture will be left/right
reversed. This function is used to project the image from
rear of the screen.
This function is used to adjust keystone distortion of the
projected image. Use the Point ed buttons to choose the
item you want to adjust.
Adjusts the Horizontal/Vertical keystone distortion of the
projected image.
Standard
Corner correction
Adjusts the corner distortion of the projected image.
Corner pattern
Choose a Corner pattern mode among Red, White, Blue,
and Off.
Store
This function is used to scale the input source to fit the
screen. Select one of the following aspect ratio which is
suitable for your cable and computer. Select “Full” if you do
not want to set aspect ratio.
Full .......Flexible aspect ratio
16:9 ......16:9 aspect ratio
16:10 ....16:10 aspect ratio
4:3 .......4:3 aspect ratio
✔Note:
• Natural wide cannot be selected when 720p, 1035i,
1080i or 1080p is selected on AV System Menu (p.46).
• When the 16:9 function is selected, Wide(16:9) is not
available in the PC and AV screen (pp.43, 51).
• When the 4:3 function is selected, Natural wide is not
available in the AV screen (p.51).
Store ......Keeps the keystone correction even when the AC
power cord is unplugged.
Reset .....Releases the keystone correction when the AC
power cord is unplugged.
Press the KEYSTONE button on the remote control to switch
the Standard (for Vertical/Horizontal) /Corner correction
adjustment. The Standard or Corner correction adjustment
dialog box appears. Use the Point ed 7 8 buttons to correct
the Standard or Corner distortion. (p.31)
Keystone
Ceiling
Rear
Screen aspect
Reset

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
