Sanyo PLC HF10000L User Manual

90
When using the optional board (DVI) “POA-AMD23ADI”, refer to the chart on the previous page.
When using other optional boards, refer to the charts below.
Supported Signal Format for Optional Board
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-480i 720x480 15.734 60.000
D-575i 720x576 15.625 50.000
D-480p 720x480 31.470 60.000
D-575p 720x575 31.250 50.000
D-1035i 1920x1035 i 33.750 60.000
D-1080i
1920x1080 i 33.750 60.000
1920x1080 i 28.125 50.000
D-720p/50 1280x720 37.500 50.000
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-720p/60 1280x720 45.000 60.000
D-1080psf/24 1920x1080 27.000 48.000
D-1080psf/25 1920x1080 28.125 50.000
D-1080psf/30 1920x1080 33.750 60.000
D-1080p
1920x1080 27.000 24.000
1920x1080 28.125 25.000
1920x1080 33.750 30.000
Dual SDI Board “POA-AMD17SDID”
Dual Link SDI Board “POA-AMD22SDIDL”
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
480i 720x480 15.734 60.000
575i 720x576 15.625 50.000
480p 720x480 31.470 59.880
575p 720x575 31.250 50.000
1035i 1920x1035 33.750 60.000
1080i/60 1920x1080 33.750 60.000
1080i/50 1920x1080 28.125 50.000
720p/50 1280x720 37.500 50.000
720p/60 1280x720 45.000 60.000
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
1080psf/24 1920x1080 27.000 48.000
1080psf/25 1920x1080 28.125 50.000
1080psf/30 1920x1080 33.750 60.000
1080p/24 1920x1080 27.000 24.000
1080p/25 1920x1080 28.125 25.000
1080p/30 1920x1080 33.750 30.000
1080p/50 1920x1080 56.250 50.000
1080p/60 1920x1080 67.500 60.000
5 BNC, S Board “POA-AMD25VD3”
Appendix
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-480i 720x480 15.734 60.000
D-575i 720x576 15.625 50.000
D-480p 720x480 31.470 60.000
D-575p 720x575 31.250 50.000
D-1035i 1920x1035 i 33.750 60.000
D-1080i
1920x1080 i 33.750 60.000
1920x1080 i 28.125 50.000
D-720p/50 1280x720 37.500 50.000
D-720p/60 1280x720 45.000 60.000
D-1080psf/24 1920x1080 27.000 48.000
D-1080psf/25 1920x1080 28.125 50.000
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-1080psf/30 1920x1080 33.750 60.000
D-1080p
1920x1080 27.000 24.000
1920x1080 28.125 25.000
1920x1080 33.750 30.000
D-1080p/50 1920x1080 56.250 50.000
D-1080p/60 1920x1080 67.500 60.000
D-2K/24psf 2048x1080 27.000 48.000
D-2K/25psf 2048x1080 28.125 50.000
D-2K/30psf 2048x1080 33.750 60.000
D-2K/24p 2048x1080 27.000 24.000

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
