51
Video Input
✔Note:
• When no signal is detected, Normal is set
automatically and the Aspect dialog box disappears.
• The adjustable range for Scale H/V and Position H/V
are limited depending on the input signal.
• Natural wide cannot be selected when 720p, 1035i,
1080i or 1080p is selected on AV System Menu (p.46).
1
2
Press the MENU button to display the on-screen
Menu. Use the Point ed buttons to select Screen and
then press the Point 8 or the SELECT button
Use the Point ed buttons to select the desired item
and then press the SELECT button.
Provides the image within a screen size keeping its original
aspect ratio.
Provides the image at the 16:9 wide screen ratio.
Screen Size Adjustment
Scales the image proportionally to fit the entire screen.
Either side of image may go over the screen.
Provides the image to fit full screen size.
Expands the right and left side of images naturally without
changing the center areas.
Provides the last stored aspect screen image.
Adjusts the screen scale and position manually with this
function.
Press the Point 8 button at Custom adj. and the Custom
adjustment menu is displayed on the screen, you can use the
Point ed buttons to choose the item you want to adjust.
Scale H/V ........... Adjusts the Horizontal/Vertical screen
scale.
H&V ................... When set to On, the aspect ratio is
fixed. Scale V appears dimmed and
becomes unavailable. Adjust Scale H,
then the screen scale is automatically
modified based on the aspect ratio.
Position H/V....... . Adjusts the Horizontal/Vertical screen
position.
Common ............ Saves the adjusted scale or position to
all the inputs. Press the SELECT button
at Common to display a confirmation
box. To save the scale or position, press
the SELECT button at "Yes", When
Custom is selected, the saved scale or
position is used.
Reset ................. Resets the all adjusted values. Press
the SELECT button at Reset to display
a confirmation box. To reset, press the
SELECT button at Yes.
Normal
Full
Wide (16:9)
Zoom
Natural wide
Custom
Custom adj.
To Next Page
