Sanyo PLC HF10000L User Manual

96
Appendix
On-Board Optional Interface Board
Input1 Input2
Dsub
-DVI
Component
-S-video
SDI
Dual
Link
SDI
Analog
PC
Scart
Digital
Analog
PC
Component
Video/
S-Video
Analog
PC
Scart
Digital
Analog
PC
Component
Video/
S-video
Digital Digital
On-Board
Input1
Analog PC
o o o o o o o o o o o o
Scart
o o o o o o o o o o o o
Digital
o o o o o o o o o o o o o
On-Board
Input2
Analog PC
o o o o o o o o o o o
Component
o o o o o o o o o o o
Video/
S-Video
o o o o o o o o o o o
List of Picture in Picture
o : Picture in Picture combinations are enabled
- : Picture in Picture combinations are disabled
✔Note:
• As for Input 3 and Input 4, combination of digital signals for Main picture and Sub picture is not available.
• When the input signal(s) is/are incompatible, X mark will be displayed on the Main/Sub picture.
• Depending on the frequency or signal type of PC/AV input,
the display resolution may be lowered or images may not be
displayed on the Main/Sub picture.
<Display resolution is lowered when;>
• Inputting PC analog signals: More than 165 MHz
<I
mages are not displayed and X mark appears when;>
• Inputting PC digital signals: More than 165MHz
Appendix

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
