Page #79 background imageLoading...
Page #79 background image
79
Troubleshooting
Before calling your dealer or service center for assistance, check the items below once again.
1. Make sure you have properly connected the projector to peripheral equipment as described on pages 20–21.
2. Check the cable connection. Make sure that all computers, video equipment, and power cords are properly
connected.
3. Make sure that all power is switched on.
4. If the projector still does not produce an image, restart your computer.
5. If an image still does not appear, disconnect the projector from your computer and check your computer
monitor’s display. A problem may be noticed with your graphics controller rather than with the projector.
(When you reconnect the projector, be sure to turn the computer and monitor off before you turn on the
projector. Turn on equipment in the order of the projector and computer.)
6. If a problem still persists, check the following solutions.
Appendix
Problem: Solutions
No power.
– Plug the power cord of the projector into the AC outlet.
Turn the MAIN ON/OFF switch to ON.
– Press the ON/STAND-BY Button to ON.
– Make sure the POWER indicator lights.
Check the indicators. If the LAMP indicator lights and the other indicators blink, the
projector cannot be turned on. (Refer to page 78.)
– Check the projection lamp. (Refer to pages 75, 76.)
– Unlock the ley lock function. (See page 63)
PIN code dialog box appears
at start-up.
PIN code lock is being set. Enter a PIN code; the “1234” or numbers you have set (see
pages 24, 63, 64)
The initial display is not
shown.
– Make sure Off ” or “Countdown Off” are not chosen at Display function.
(See page 53)
The initial display is not
same with the default one.
– Make sure “User” or Off” are not chosen at Logo select function.
(See page 59)
When the projector is on and
you press the input button,
an icon other than the Lamp
mode icon appears.
That is the Filter warning icon. Refer to page 71.
An icon other than Input
mode or Lamp mode icon
appears.
That is the Lamp replacement icon or the Filter warning icon. See pages 71, 75.
No image.
– Check the connection between your computer or video equipment and the projector.
See if the input signal is correctly output from your computer. Some laptop computers
may need to be changed the setting for monitor output when connected to the
projector. See your computer’s instruction manual for the setting.
– It takes about 20 seconds to display an image after turning on the projector.
– See if the selected system is corresponding with your computer or video equipment.
Select correct input source once again through menu operation (See pages 32-34).
Make sure the temperature is not out of Operating Temperature
(41˚F–10F [5˚C
40˚C]).
– Make sure that the shutter is open. (See pages 28, 65

Table of Contents

Other manuals for Sanyo PLC HF10000L

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sanyo PLC HF10000L and is the answer not in the manual?

Sanyo PLC HF10000L Specifications

General IconGeneral
Matrix size1.65 \
Matrix type3-panel (p-Si TFT active)
Projection distance- m
Vertical scan range48 - 100 Hz
Horizontal scan range15 - 120 kHz
Projection technologyLCD
Contrast ratio (typical)3000:1
Screen size compatibility- \
Projector native resolution-
Keystone correction, horizontal30 °
InterfaceUSB
Power LEDYes
RS-232 ports2
Dimensions (WxDxH)530 x 757 x 268 mm
FocusAuto
Focal length range- mm
Noise level43 dB
Noise level (economic mode)39 dB
Dot clock scanning frequency230 MHz
Lamp power380 W
Lamps quantity2 lamp(s)
Light source typeLamp
Service life of light source2000 h
Service life of light source (economic mode)3000 h
Composite video in0
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity1
Wi-FiNo
Analog signal format systemNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product colorGray
Power consumption (standby)18 W
Power consumption (typical)955 W
Cables includedAC, RS-232
Weight and Dimensions IconWeight and Dimensions
Weight27600 g
