Sanyo PLC HF10000L User Manual

93
Configurations of Terminals
ANALOG TERMINAL(Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
CONTROL PORT CONNECTOR (D-sub 9 pin)
DIGITAL (DVI-D) TERMINAL (DVI 24 PIN)
1
9
17
2
10
18
3
11
19
4
12
20
5
13
21
6
14
22
7
15
23
8
16
24
USB PORT(Series B)
2
3 4
1
1 3 5 7 9 11 13 15 17 19
1816141210 8642
HDMI TERMINAL(19 pin Type A)
8 7 6 5 4 3 2 1
LAN PORT (RJ-45)
1
TX+
2
TX–
3
RX+
4
- - -
5
- - -
6
RX–
7
- - -
8
- - -
Serial
1
- - -
2
RXD
3
TXD
4
- - -
5
SG
6
- - -
7
- - -
8
- - -
9
- - -
1
Vcc
2
– Data
3
+ Data
4
Ground
1
T.M.D.S. Data2–
9
T.M.D.S. Data1–
17
T.M.D.S. Data0–
2
T.M.D.S. Data2+
10
T.M.D.S. Data1+
18
T.M.D.S. Data0+
3
T.M.D.S. Data1Shield
11
T.M.D.S. Data1 Shield
19
T.M.D.S. Data0 Shield
4
- - -
12
- - -
20
- - -
5
- - -
13
- - -
21
- - -
6
DDC Clock
14
+5V Power
22
T.M.D.S. Clock Shield
7
DDC Data
15
Ground (for +5V)
23
T.M.D.S. Clock+
8
- - -
16
Hot Plug Detect
24
T.M.D.S. Clock–
1
T.M.D.S. Data 2+ Input
11
Ground (T.M.D.S. Clock)
2
Ground(T.M.D.S. Data 2)
12
T.M.D.S. Clock– Input
3
T.M.D.S. Data 2– Input
13
- - -
4
T.M.D.S. Data 1+ Input
14
- - -
5
Ground (T.M.D.S. Data 1)
15
SCL
6
T.M.D.S. Data 1– Input
16
SDA
7
T.M.D.S. Data 0+ Input
17
Ground (DDC/CEC)
8
Ground (T.M.D.S. Data 0)
18
+5V Power
9
T.M.D.S. Data 0– Input
19
Plug insert detection
10
T.M.D.S. Clock+ Input
1
Red Input
9
+5V Power
2
Green Input
10
Ground (Vert. sync)
3
Blue Input
11
Ground
4
- - -
12
DDC data
5
Ground (Horiz. sync.)
13
Horiz. sync.
6
Ground (Red)
14
Vert. sync.
7
Ground (Blue)
15
DDC Clock
8
Ground (Green)
Appendix

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
