Sanyo PLC HF10000L User Manual

48
Video Input
1
2
Press the Point 7 button to decrease the contrast; press
the Point 8 button to increase the contrast (from 0 to 63).
Press the Point 7 button to decrease the brightness;
press the Point 8 button to increase the brightness (from
0 to 63).
Press the Point 7 button decrease the intensity of the
color; press the Point 8 button increase the intensity of
the color (from 0 to 63).
Press the Point 7 8 buttons to adjust the tint value to get
a proper color balance (from 0 to 63).
Image adjust
Selected Image mode
Press the MENU button to display the On-Screen
Menu. Use the Point ed buttons to select Image
adjust and then press the Point 8 or the SELECT
button.
Use the Point ed buttons select the desired item
and then press the SELECT button to display the
adjustment dialog box. Use the Point 7 8 buttons to
adjust the setting value.
Use the Point 7 8
buttons to adjust
the setting value.
Image Adjustment
Refer to pages 40 and 41.
Press the Point 7 button to lighten red tone; press the
Point 8 button to deepen red tone (from 0 to 63).
Press the Point 7 button to lighten green tone; press the
Point 8 button to deepen green tone (from 0 to 63).
Press the Point 7 button to lighten blue tone; press the
Point 8 button to deepen blue tone (from 0 to 63).
Use the Point 7 8 buttons to select the desired Color temp.
level (XLow, Low, Mid or High).
Contrast
Brightness
Color management
Color
Tint
Color temp.
White balance (Red)
White balance (Green)
White balance (Blue)

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
