37
Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Position H and Position V positions to
conform to your computer.
To store the adjusted parameters.
The adjusted parameters from the Auto PC Adjustment can be
stored in the projector. Once the parameters are stored, the setting
can be done just by selecting Mode in PC SYSTEM Menu (p.36).
See “Manual PC Adjustment” on pages 38-39.
3Note:
• Fine sync, Total dots, Position H and Position V position of certain
computers cannot be fully adjusted with the Auto PC Adjustment
function. When the image is not provided properly with this operation,
manual adjustments are required. (pp.38-39)
• Auto PC Adjustment cannot be operated in Digital Signal Input on the
DVI terminal and 480p, 575p, 480i, 575i, 720p, 1035i, 1080i or 1080p is
selected on the PC SYSTEM Menu.
• Depending on the condition of signals and the type and length of
cables, the signals may not be properly viewed.
The Auto PC adjustment function can be operated directly by
pressing the AUTO PC button on the remote control.
AUTO PC button
Remote Control
Computer Input
PC adjust Menu
Press the MENU button to display the On-Screen Menu. Use
WKH3RLQWŸźEXWWRQVWRVHOHFWPC adjust and then press
WKH3RLQWŹRUWKH6(/(&7EXWWRQ
1
2
8VHWKH3RLQWŸźEXWWRQVWRVHOHFWAuto PC adj. and then
press the SELECT button.
Auto PC adj.
Fine sync
Total dots 1366
Position H 0
Position V 0
Current mode
Clamp 0
Display area H 1024
Display area V 768
Reset
Mode free
Store
0
8VHWKH3RLQWŸźEXWWRQVWRVHOHFWAuto PC
adj. and press the SELECT button.
Please wait... appears while the Auto PC
adjustment is in process.
Auto PC Adjustment
Direct Operation
Menu Operation
Auto PC adj.
To Next Page
