38
Some computers employ special signal formats which may not be tuned by Multi-Scan system of this projector. Manual PC
Adjustment enables you to precisely adjust several parameters to match those special signal formats. The projector has
10 independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific
computer.
3Note: The PCAdjust Menu cannot be operated when the digital signal input on the DVI terminal is selected on PC System
Menu.
Use the Point ŻŹbuttons to adjust the value, eliminating a flicker
from the image displayed (from 0 to 31).
Use the Point ŻŹ buttons to adjust the number of total dots in one
horizontal period to match your PC image.
Use the Point ŻŹ buttons to adjust the horizontal picture position.
Use the Point ŻŹ buttons to adjust the vertical picture position.
Press the SELECT button to show H-sync freq. and V-sync freq. of
the connected computer.
Use the Point ŻŹ buttons to adjust the clamp level. When the
image has dark bars, try this adjustment.
Use the Point ŻŹ buttons to adjust the horizontal area displayed
by this projector.
Use the Point ŻŹ buttons to adjusts the vertical area displayed by
this projector.
Computer Input
PC adjust Menu
1
2
Press the MENU button to display the On-Screen Menu. Use
WKH3RLQWŸźEXWWRQVWRVHOHFWPC adjust and then press the
3RLQWŹRUWKH6(/(&7EXWWRQ
8VHWKH3RLQWŸźEXWWRQVWRVHOHFWWKHGHVLUHGLWHPDQGWKHQ
press the SELECT button to display the
DGMXVWPHQWGLDORJER[8VHWKH3RLQWŻŹEXWWRQVWRDGMXVWWKH
setting value.
Fine sync
Total dots
Position H
Position V
Current mode
Clamp
Display area H
Display area V
Manual PC Adjustment
