Sanyo PLC-XM100L User Manual

39
Computer Input
3Note:
• Display area (H/V) cannot be selected when 480i, 575i,
480p, 575p, 720p, 1035i or 1080i is selected in the PC
System Menu (p.36).
• When input computer signal to the projector, PC adjust function
will become available.
Auto PC adj.
Fine sync
Total dots 1366
Position H 0
Position V 0
Current mode
Clamp 0
Display area H 1024
Display area V 768
Reset
Mode free
Store
0
store?
Store
Free
Vacant
This mode has stored
parameters.
Values of Total dots, Position H,
Position V, Display area H and
Display area V.
Press the SELECT button to
store the data.
Press the MENU button
to close this dialog box.
Mode free
Store
To store the adjusted data, select Store and then press the Point
ŹRUthe SELECT button. Move the highlight to one of the Modes
1 to 10 in which you want to store, and then press the SELECT
button.
To clear the stored data, select Mode free and then press the Point
ŹRUthe SELECT button. Move the highlight to the Mode that you
want to clear and then press the SELECT button.
To reset the adjusted data, select Reset and press the SELECT
button. A confirmation box appears and then select Yes. All
adjustments will return to their previous figures.
Reset
Mode free
Store
Press the SELECT
button to clear the
stored data.

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
